- Five (5) self-loading peristaltic pumps with one of them for plasma recirculation inside the separation chamber in order to stabilize the interface and regulate the hematocrit on it, in productive procedures.
- Three (3) exchangeable centrifugation plate, in order to hold different separation chambers for different type of procedures. Fast easy and safe locking.
- Color display with surrounding soft-keys to handle easy-to-use software.
- With online help to advice the operator about the steps to follow.
- With Donor/Patient/Operator dedicated display to monitor the procedure separately.
- With dedicated printer (included) to register all the events occurred during the procedure. With comprehensive printout for reporting.
- Double needle Patient/Donor vein access, with single needle capabilities in selected procedures.
- Exchangeable printed layout to help the operator on the mounting of the different kits
- Automatic saline perfusion system in case that procedure holds, or type “Keep Vein Open” system.
- Total extracorporeal volemia < 180ml for all DN procedures.
- Hemolisis/Red cell sensor for Plasma line monitoring and Platelets sensor on Cell line.
- Wireless connection capabilities to be linked with dedicated data management software.
- Big rear wheels in order to improve the equipment handling.
Eleven (11) treatment and productivity programs present, with the following characteristics:
a) Platelet:
1. Double needle PLT collection with Five (5) days storage bags.
2. Single needle PLT collection with Five (5) days storage bags.
- Both procedures with Plasma collection capabilities and performed.
- Leukocyte-depleted product by the centrifugation system itself (not filtered), with WBC contamination < 5 x 10E5.
b) Stem Cells:
3. Peripheral blood stem cell collection, lymphocyte collection or depletion.
4. Peripheral blood stem cell collection with reduced volume capability.
5. Mononuclear cell collection or depletion.
6. Granulocyte collection.
7. Bone Marrow stem cell processing with automatic transfer between the donation and reinfusion bag (BMSC).
- All Stem Cell procedures with CD34+ cell estimation and procedure time forecast.
- All Stem Cell procedures with automatic Plasma collection capabilities.
c) Therapy:
8. Depletion of platelets or white blood cells.
9. Therapeutic Red Cell exchange or depletion.
10. Therapeutic Plasma exchange with isovolemic and automatic fluid balancing and Buffy Coat reinfusion.
11. Therapeutic plasma treatment (e.g. immunoadsorption, plasma filtration) with isovolemic and automatic fluid balancing and Buffy Coat reinfusion, (no additional hardware required and integrated Pressure Monitor for Column/Filter monitoring).
- It is versatile, confidence in quality and performance
- Possessing good average in Platelet collection efficiency.
- Leukocyte depleted platelet concentrates collection with reliable WBC reduction technology.
- collection outside of centrifuge, is visible during collection with lower cell activation
- It has five pumps, one separate pump for ACD-A.
- Centrifuge speed upto 2200 rpm with high gm force which increases purity.
- Unexcelled donor safety, having fully automated ACD-A drip detector/leak sensor test, with automatic
keep-vein-opened (KVO) in stop-mode.
- Newly designed apheresis sets, with new single needle process, having hemolysis monitor.
- Incomparable operating comfort, color displays having table and support for holding the chamber.
- It has effect noise reduction measures.
- Innovative software for interconnection of several cell separators through “Apheresis Master”
- Weight 130 kg Size 60 x 66 cm.
