Navios

The Navios Flow Cytometer is a clinical system that delivers analytical excellence by coupling extraordinary sensitivity, resolution and dynamic range with high-speed data collection.

The Navios Flow Cytometer is a clinical system that delivers analytical excellence by coupling extraordinary sensitivity, resolution and dynamic range with high-speed data collection. With superior detection capabilities, the Navios provides accurate measurements, especially for rare events, which is critical to clinical diagnosis and monitoring. The fully-featured, easy-to-use Navios software provides tools to improve the quality of results as well as optimize workflow efficiencies in a clinical lab.

Designed to fit your needs, today and tomorrow, the Navios flow cytometer provides efficient acquisition of superior quality data from up to 10 colors with advanced optical design for enhanced sensitivity for multicolor assays. With customized forward scatter, to achieve the most accurate size measurement, and optimized electronics for high resolution and fast, accurate processing.

Navios is optimized for unparalleled signal to noise resolution in all parameters and its quick and easy setup of automated walk-away processing improves your workflow while its remote diagnostics minimize downtime and allow you to maximize lab productivity.

Electronics provide accurate and efficient digital signal processing at high event rates over a wide dynamic range of fluorescence intensities. These benefits are packaged in a compact analyzer that delivers stable performance over long periods of time and across a wide range of operating temperatures.

The Navios houses up to three highly reliable, solid-state lasers in standard red and blue, with violet available as an option. Easily interchanged optical filters facilitate detection of a variety of dyes and wavelengths.

An innovative forward-scatter detector provides up to three measurements of cell size and visualization of particles down to 0.404 µm in diameter. A side-scatter detector incorporates an independently focused, high-performance photodiode with electronic attenuation. Six fluorescence detectors provide simultaneous acquisition of up to six fluorescence signals. Up to four fluorescence detectors can be added to the system, enabling concurrent reading of up to 10 colors.

Simultaneous measurements of integral, peak and width are available for all parameters, including scatter and fluorescence signals. A selection of up to 62 parameters can be processed per analysis, at acquisition rates of 25,000 events-per-second, with high yield. Three scalable configurations allow for the future addition of more lasers and fluorescence detectors as the applications for complex multi-color flow cytometry expand.

Available in 3 configurations

6 color 2 Laser (5+1)

8 color 2 Laser (5+3)

10 color 3 Laser (5+3+2)

Innovative laser cartridges

Picomotor driven beam steering optics

Laser control to conserve laser life

Design for laser flexibility

Customer temperature regulation Plug and play filters allow rapid instrument reconfiguration between experiments

Filters are easily accessible and interchangeable with no tools required

Software features:

Multi-User Administration
